Originally known as Kingkey financial center, the building is 441.8 meters high and has 100 floors. It is currently the tallest building in Shenzhen, the fourth tallest building in mainland China and the tenth tallest building in the world.

Jingji 100 is a super large comprehensive building complex integrating financial office buildings, six-star luxury hotels, large-scale commercial buildings, high-grade apartments and residential buildings. Its commercial characteristics determine that Jingji 100 is faced with complex personnel situation: a large number of internal office personnel authority management and a large number of customer visits, express delivery, etc.

In order to pursue high quality, high safety and high intelligence, and reach the international top level, Jingji 100 requires that all the elevator hall quick access doors, floor access doors and elevators in the building should be authorized to use by swiping cards; quick access doors and elevators should realize linkage self-service calling and dispatching functions. The building also provides corresponding leisure consumption points for internal staff to realize card consumption. At the same time, we also need to provide a set of perfect software management platform to facilitate customers to conveniently manage the personnel in and out of the building, so as to ensure the operation of Kingkey 100 in an effective, safe and energy-saving environment.

As the service provider of the project, Hanjun intelligent system (Shanghai) Co., Ltd. has rich technology precipitation in the field of all-in-one card. With a deep understanding of user needs, it integrates its unique all-in-one card management technology and application to create a "smart brain" for Jingji 100 and create a safer, more convenient and more comfortable living space. As a 100% equity owner of Hanjun intelligent system (Shanghai) Co., Ltd., Hikvision reveals the "intelligent brain" (intelligent self-service visitor management system) of Jingji 100 based on "personnel control business".

Application background: the flow of visitors is very large, and the security problem is facing a severe test

It is estimated that in the peak hours, the visitor flow of Jingji 100 is about 1000, and the number of visitors per day is no less than 3000. The traditional visitor management can no longer meet the needs of customers.

Combined with the structural characteristics and passenger flow characteristics of Jingji 100, is it possible to develop an "intelligent" self-service visitor management system that meets the requirements of the building, and make the following planning for the system layout of the building: the building is divided into low area and high area, you need to take the elevator to go to the high area, and replace the elevator on the 39F or 40F transfer floor. From the perspective of property safety and management, the transfer elevator starts the elevator control system In general, all visitors need to go to - 1F and 1F to apply for visitor cards first. Visitors of the whole building are concentrated in two front desks to apply for visitor cards manually. In peak hours, 400 visitor cards need to be applied for an hour, which is a heavy workload.

After in-depth communication with users, combined with our deep understanding of user needs in the field of all-in-one card, we have "customized" a set of "intelligent brain" (intelligent self-service visitor management system) based on "personnel management and control business" for customers, and the user's evaluation after use is "a perfect solution".

Typical meaning: all in one card is deeply integrated with access control, elevator, visitor, parking and other systems

1、Integrated access control management, visitor system, information management and other subsystems

The project constructs a unified all-in-one card management platform, which serves as the data gathering center of access control, elevator management, visitor, parking management, express door and consumption, as well as the core of authority setting and distribution. In the aspect of system integration, the integration of all-in-one card and hotel management system can realize the common use of all-in-one card for hotel guests to the office floor; the integration of all-in-one card and monitoring system can realize the linkage camera and alarm video pop-up; the integration of all-in-one card and BA system can meet the overall control requirements; the integration of all-in-one card and elevator system can achieve the function of automatic allocation of elevator and control authority by swiping card; the integration of all-in-one card and shopping mall can Sales management system for integration, to achieve full shopping discount parking.

2、The industry's first integration with Mitsubishi Elevator socket interface

Mitsubishi signal processor (e-lip), as a socket TCP server, can support multiple clients to connect at the same time. Through multi-party communication, Hikvision has completed the integration with Mitsubishi signal interface, which is the first in the industry.

1）As the client of Scoket TCP client, the gateway network controller uses the method of short connection. When there is information to be sent, it is connected to Mitsubishi signal processor (e-lip).As the client of Scoket TCP client, the gateway network controller uses the method of short connection. When there is information to be sent, it is connected to Mitsubishi signal processor (e-lip).

2）When the building staff swipe the card on the express door, the express door network controller judges the authority of the card number and sends information to Mitsubishi signal processor (e-lip) according to the judgment result.

3）Mitsubishi signal processor (e-lip) receives the information, after processing, it will return the processing results to the network controller.

The picture shows the integration of Hikvision and Mitsubishi elevator

Solution: multiple subsystems take "one card management platform" as the center

Jingji 100 has established an all-in-one card management platform. The platform needs to provide effective operator management, personnel data management, personnel authority granting, swipe card and alarm event query functions to facilitate centralized management of customers.

1、Floor access door control: it can give the corresponding personnel access and time, effectively control the flow of internal personnel and visitors, at the same time, the access control point has the function of anti damage alarm and door open alarm；

2、Control of external visitors: in today's era of rapid development of computer technology, we only need to sit in the office to complete the visitor's appointment, and directly pick up the card when we arrive at the destination. There is no need to wait or queue up, which effectively saves the visitor's time and reduces the personnel load of the hall. The intelligent self-service visitor management system customized and developed by Hikvision for Kingkey 100 fully supports the on-site appointment mode and the mode that the interviewees help visitors to make their own appointment. It is a safe, fast and humanized management system。

The intelligent self-service visitor management system is not only relying on manual registration to realize the authorization and issuance of visitor cards. Visitors only need to make an appointment through the enterprise website of the building according to the requirements. After being confirmed by the interviewee, the system will automatically send a short message indicating that the application has been confirmed. Visitors only need to hold the pre entered ID card and send it to the self-service visitors The whole process is like buying a high-speed rail ticket by ourselves. It's very convenient to pick up the card in 3 seconds。

3、Integration of elevator and express door: during rush hours of work and visitors, the express door judges the authority. At the same time, the system will assign an elevator to the passing personnel on the LCD screen above the gate. The personnel and other personnel with the same floor will take the elevator directly to the destination floor, and the elevator will not stop in the middle, which effectively blocks the entry of illegal personnel and improves the operation efficiency of the elevator When passing through the gate, the system will automatically judge the number of people in the elevator hall. When the number exceeds the limit, there will be a corresponding prompt. At the same time, the gate will enter the disabled state. When the number of people is reduced, the gate will automatically resume the operation mode。
